Leica DA300 1 Watt Signal Transmitter | Multi-Frequency Utility Tracing | Precise Signal Application

The Leica DA300 1-Watt Signal Transmitter is a precision instrument designed for applying high-accuracy trace signals to buried infrastructure. By facilitating the mapping of underground utilities, this transmitter ensures site safety and efficient excavation processes. It offers a versatile frequency range and variable power output to adapt to diverse site conditions and utility materials.

How does the Leica DA300 improve utility detection?

It applies a trace signal using five selectable frequencies including 512Hz, 640Hz, 8kHz, 33kHz, 83kHz, and 131kHz. This allows operators to optimize the signal for specific environments, ensuring the Leica DD300 locator range can map buried assets with maximum precision.

What are the power output capabilities of the DA300?

The unit provides a variable power output reaching up to 1 Watt, giving users control over signal strength based on the depth of the utility. This functionality allows for effective signal application across various infrastructure depths and conductive materials.

What battery options are available for field use?

The transmitter is standardly supplied with four LR20 alkaline batteries for immediate deployment and reliable performance. For extended operations, an optional Li-Ion battery pack is available to increase longevity and reduce the frequency of battery changes.

Trace Frequencies	512Hz, 640Hz, 8kHz, 33kHz, 83kHz, 131kHz
Power Output	Variable, up to 1 Watt
Power Supply	4x LR20 Alkaline batteries (Li-Ion optional)
Warranty	3 Years
Compatibility	Leica DD300 Locator range

• Pair with the Leica DD300 Connect Locator for advanced utility mapping.
• Extend runtime with the Leica Li-ion Battery Pack for high-demand projects.
• Apply signals directly to pipes using the Leica 4" Transmitter Clamp.
• Safeguard equipment in the field with the Leica System Carry Bag.
