Radiodetection PCMx & Tx-25 Kit | Pipeline Mapping | Corrosion Protection Survey
The Radiodetection PCMx and Tx-25 PCM Tx Kit provides a comprehensive field solution for assessing cathodic protection systems and locating buried utility pipelines. By combining advanced mapping technology with rugged hardware, this kit allows technicians to achieve accurate current measurements and identify coating defects with high repeatability. The inclusion of an A-frame ensures optimized ground contact, making it a critical tool for pipeline integrity management.
What are the primary components of this PCMx kit?
This kit features the PCMx locator paired with a Tx-25 transmitter, providing the necessary signal generation and detection for pipeline current mapping. It also includes a dedicated A-frame and a soft carry bag to protect and transport the entire system during field operations.
How does the A-frame enhance locating accuracy?
The A-frame is designed to establish reliable ground contact, which is essential for fault finding and detecting coating holidays in cathodic protection systems. It works in conjunction with the PCMx to pinpoint the exact location of signal leakage through soil.
Is this system optimized for mobile field technicians?
Yes, the kit is designed for maximum transportability, featuring a soft bag for the A-frame and an additional soft carry bag for the transmitter and locator. This setup allows technicians to carry Radiodetection precision equipment easily across various field terrains without compromising protection.
| Manufacturer | Radiodetection |
| Core Locator | PCMx |
| Transmitter Model | Tx-25 PCM Tx |
| Detection Technology | Pipeline Current Mapping (PCM) |
| Included Support | A-Frame with Lead |
| Storage | Soft Carry Bag and A-Frame Bag |
