Radiodetection EKKO_Project V6 Bridge Deck Module | GPR Concrete Analysis | ASTM 6087 Mapping

The Radiodetection EKKO_Project Bridge Deck Condition Module is a highly specialized technical add-on for the EKKO_Project GPR analysis suite. It is engineered to streamline the interpretation of rebar reflections within concrete decks, providing engineers with data-driven insights into structural integrity. By automatically calculating signal attenuation, the software identifies chloride ingress and corrosion, facilitating rapid assessments of bridge health.

How does the V6 Bridge Deck Module streamline rebar analysis?

The software utilizes advanced algorithms for automated rebar picking and interpretation, significantly reducing the manual labor involved in processing complex concrete data. This automation allows for the creation of visual heat maps that clearly indicate areas of potential structural deterioration and corrosion.

What standards and data formats does this GPR software support?

This module is fully compliant with ASTM 6087 standards for bridge GPR surveys, ensuring that data collection and reporting meet industry-wide regulatory requirements. Survey results can be exported in PDF and GIS-compatible formats, allowing for seamless integration into broader maintenance management systems.

What are the technical requirements for operating the Bridge Deck Module?

The Bridge Deck Module functions as an expansion of the core suite and strictly requires EKKO_Project Core or higher to operate. It provides the specialized Bridge Deck Condition Index (BDCI) mapping tools necessary for high-level professional structural surveys.

Compatible Software and Accessories

• Required Foundation: EKKO_Project V6 Core Software Bundle
• Additional Analysis Module: EKKO_Project V6 Pavement Analysis Module
• Advanced Data Processing: EKKO_Project V6 Examine Software Bundle
• Visualization Suite: EKKO_Project V6 Reveal Software Bundle
